Oracle RAC Backup and Recovery

1 .  RAC Backup and Recovery Concepts

• Backup in RAC: In Oracle RAC, backups are crucial for ensuring data integrity and availability. RAC backups are performed across multiple instances of the cluster, and RMAN (Recovery Manager) coordinates backup activities.

• Parallelism: RAC allows parallel backups using RMAN, utilizing multiple nodes and channels, which speeds up the process.

• Backup Types: Includes full backups, incremental backups, and archivelog backups. These can be performed at the database, tablespace, or datafile level.

• Recovery Concepts: RAC recovery involves restoring data and bringing it to a consistent state across all instances. Common scenarios include instance recovery, media recovery, and complete or point-in-time recovery.

2 . Configuring RMAN for RAC

• RMAN Configuration: RMAN must be configured to handle multiple instances in a RAC environment. The configuration is stored in the database control file or recovery catalog.

• Channel Configuration: RMAN uses channels for backup and recovery operations. In RAC, you can configure multiple channels to distribute the load across instances.

• Automatic Channel Allocation: RMAN automatically allocates channels across RAC nodes based on the load, but this can also be manually configured.

• Instance-Specific Backups: You can perform instance-specific backups, though typically backups are coordinated across all instances.

3 . Performing RAC Backups Using RMAN

• Full Database Backup: A full backup can be taken across all RAC instances simultaneously, ensuring consistency.

• Incremental Backup: Incremental backups capture only the changes since the last backup, reducing the backup size and duration. RMAN manages incremental backups efficiently across all RAC nodes.

• Archivelog Backup: Archive logs generated on all RAC nodes need to be backed up to ensure that all committed transactions can be recovered.

• Backup Storage: Backups can be stored on ASM disk groups, file systems, or external storage. RAC environments often use shared storage to centralize backups.

4 . RAC Recovery Scenarios

• Instance Recovery: If a RAC node fails, the surviving instances perform instance recovery, automatically applying the redo logs to ensure data consistency.

• Media Recovery: If data files are lost or corrupted, you can restore them from backups and perform recovery using the archived redo logs and RMAN.

• Disaster Recovery: In severe cases where multiple nodes or the entire cluster is affected, complete recovery using backups and archived logs is necessary. RMAN can automate this process across nodes.

• Point-in-Time Recovery: In cases of logical corruption, point-in-time recovery (PITR) can be used to restore the database to a previous state. This can be done for the entire database or specific tablespaces.

5 . Flashback Technology in RAC Environments

• Flashback Overview: Flashback technology in Oracle RAC provides a set of features that allow you to quickly undo changes to the database without needing a full restore from backups.

• Flashback Database: Enables you to rewind the entire RAC database to a previous point in time, useful for recovering from logical errors like accidental data deletion.

• Flashback Table: Allows you to revert specific tables to a previous state without affecting the rest of the database.

• Flashback Drop: Provides the ability to recover dropped tables from the recycle bin.
• Flashback Data Archive: Maintains historical versions of data, allowing you to query older versions of rows.

6 .  What are the high level steps to convert a non-RAC database to RAC database?

 Two phase approach can be followed to convert a database from non-RAC to RAC.

1. Duplicate single instance non-ASM database to ASM using RMAN
2. Manually convert single instance database to RAC

Prerequisites

• Install and configure Clusterware

• Install and configure Automatic Storage Management (ASM)

• Install Oracle Database Software

• Standalone database and RAC must be on same Database version

1. Estimate used space for Non-RAC database
2. Create password file and init.ora file for RAC environment

Initfile contents (basic)

db_name ="ORADB"

instance_name =ORADB

control_files =‘+DATA’, ‘+FLASH’

db_create_file_dest='+DATA'

db_recovery_file_dest='+FLASH'

db_create_online_dest_1=’+DATA’

db_create_online_dest_2=’+FLASH’

log_archive_dest_1='LOCATION=+FLASH’

3. Configure Oracle Listener and tnsnames.ora file
4. Duplicate the database to RAC server using RMAN
